Commutation Relations: Algebra of Quantum Observables

0
commutation relations

Table of Contents

  1. Introduction
  2. Operators and Observables
  3. Definition of Commutator
  4. Mathematical Properties of Commutators
  5. Canonical Commutation Relations
  6. Position-Momentum Commutation
  7. Angular Momentum Commutation Relations
  8. Spin and Pauli Matrices
  9. Consequences for Measurement
  10. Commutators and Uncertainty Principle
  11. Lie Algebras and Structure Constants
  12. Commutator Algebra in Matrix Mechanics
  13. Time Evolution and Commutators
  14. Symmetries and Conserved Quantities
  15. Applications in Quantum Field Theory
  16. Conclusion

1. Introduction

Commutation relations are fundamental to the algebraic structure of quantum mechanics. They encode the non-commutative nature of quantum observables and lie at the heart of quantum dynamics, measurement, and uncertainty.


2. Operators and Observables

In quantum mechanics:

  • Observables are represented by operators on a Hilbert space
  • The order in which operators act matters:
    \[
    \hat{A}\hat{B} \neq \hat{B}\hat{A}
    \]
    This is a key departure from classical physics.

3. Definition of Commutator

Given two operators \( \hat{A} \) and \( \hat{B} \), the commutator is defined as:

\[
[\hat{A}, \hat{B}] = \hat{A}\hat{B} – \hat{B}\hat{A}
\]

  • If \( [\hat{A}, \hat{B}] = 0 \): operators commute
  • If not: they are non-commuting, and their measurements are incompatible

4. Mathematical Properties of Commutators

  • Linearity:
    \[
    [\hat{A} + \hat{B}, \hat{C}] = [\hat{A}, \hat{C}] + [\hat{B}, \hat{C}]
    \]
  • Jacobi Identity:
    \[
    [\hat{A}, [\hat{B}, \hat{C}]] + [\hat{B}, [\hat{C}, \hat{A}]] + [\hat{C}, [\hat{A}, \hat{B}]] = 0
    \]
  • Commutator with product:
    \[
    [\hat{A}, \hat{B}\hat{C}] = [\hat{A}, \hat{B}]\hat{C} + \hat{B}[\hat{A}, \hat{C}]
    \]

5. Canonical Commutation Relations

The most fundamental commutation relation in quantum mechanics:

\[
[\hat{x}, \hat{p}] = i\hbar
\]

Where:

  • \( \hat{x} \): position operator
  • \( \hat{p} \): momentum operator

It expresses the non-commutativity of phase space coordinates.


6. Position-Momentum Commutation

In one dimension:

\[
\hat{x} \psi(x) = x \psi(x), \quad \hat{p} \psi(x) = -i\hbar \frac{d}{dx} \psi(x)
\]

Then:

\[
[\hat{x}, \hat{p}] \psi(x) = i\hbar \psi(x)
\]

Confirms the canonical commutator.


7. Angular Momentum Commutation Relations

Angular momentum components \( \hat{L}_x, \hat{L}_y, \hat{L}_z \) obey:

\[
[\hat{L}_x, \hat{L}_y] = i\hbar \hat{L}_z
\]
\[
[\hat{L}_y, \hat{L}_z] = i\hbar \hat{L}_x
\]
\[
[\hat{L}_z, \hat{L}_x] = i\hbar \hat{L}_y
\]

These form the Lie algebra of the rotation group SO(3).


8. Spin and Pauli Matrices

Spin-1/2 observables are represented by Pauli matrices:

\[
[\sigma_x, \sigma_y] = 2i\sigma_z, \quad \text{and cyclic permutations}
\]

This reflects the algebra of angular momentum at the quantum level.


9. Consequences for Measurement

Non-commuting operators:

  • Cannot be simultaneously diagonalized
  • Cannot have well-defined values in the same quantum state
  • Measurement of one affects the uncertainty of the other

10. Commutators and Uncertainty Principle

From:

\[
[\hat{A}, \hat{B}] = i\hat{C}
\]

We get:

\[
\Delta A \Delta B \ge \frac{1}{2} |\langle [\hat{A}, \hat{B}] \rangle|
\]

For position and momentum:

\[
\Delta x \Delta p \ge \frac{\hbar}{2}
\]


11. Lie Algebras and Structure Constants

If:

\[
[\hat{T}_a, \hat{T}_b] = i f^{abc} \hat{T}_c
\]

Then \( f^{abc} \) are the structure constants of a Lie algebra. Commutators encode the symmetry algebra of quantum systems.


12. Commutator Algebra in Matrix Mechanics

Heisenberg’s original formulation was built on:

  • Matrix observables
  • Operator algebra
  • Time evolution governed by commutators:
    \[
    \frac{d\hat{A}}{dt} = \frac{i}{\hbar}[\hat{H}, \hat{A}] + \left(\frac{\partial \hat{A}}{\partial t}\right)
    \]

This is equivalent to Schrödinger’s picture.


13. Time Evolution and Commutators

Heisenberg equation of motion:

\[
\frac{d\hat{A}}{dt} = \frac{i}{\hbar}[\hat{H}, \hat{A}]
\]

If \( [\hat{H}, \hat{A}] = 0 \), then \( \hat{A} \) is conserved — i.e., a constant of motion.


14. Symmetries and Conserved Quantities

Symmetry operations correspond to unitary operators:

  • If \( \hat{U} \) is a symmetry:
    \[
    \hat{U}^\dagger \hat{H} \hat{U} = \hat{H}
    \]
  • If \( [\hat{H}, \hat{G}] = 0 \), then \( \hat{G} \) is conserved

This forms the basis of Noether’s theorem in quantum systems.


15. Applications in Quantum Field Theory

  • Creation and annihilation operators obey commutation (bosons) or anticommutation (fermions) relations
  • Gauge symmetries are described via commutator algebra of field operators
  • Commutators dictate causal structure in relativistic theories

16. Conclusion

Commutation relations are the algebraic engine of quantum mechanics. They define how observables interact, reveal the structure of quantum symmetries, and give rise to fundamental limits like the uncertainty principle. Understanding and manipulating commutators is essential for analyzing quantum systems in mechanics, information, and field theory.


.

Today in History – 15 July

0
today in history 15 July

today in history 15 July

1783

Sir Jamsetjee Jeejeebhoy, great Indian Merchant, Industrialist and philanthrophist, was born in Bombay. He aided famine relief, financed public works like wells, roads, causeways and bridges; founded dispensaries and hospitals; established educational institutions and scholarship funds; etc. He was receipent of a Knighthood and many medals.

1788

Ghulam Kadir, the infamous son of Jabita Khan, conquered Delhi.

1888

The Bandai volcano erupted on the Japanese island of Honshu on this day in 1888, killed hundreds and buryed many nearby villages in ash.

1903

Kumaraswamy Kamraj, great freedom fighter, social reformer, political leader and member of the Lok Sabha, was born in a trading family at Virudhunagar in Tamil Nadu.

1904

Mogubai Kurdikar, veteran singer of ‘Jaipur Gharana’, was born.

1917

Tukaram Tanaji Sawant, educationist and famous Hindi writer, was born at Pokharam, (Maharashtra).

1918

On this day in 1918, near the Marne River in the Champagne region of France, the Germans began their final offensive push of World War I.

1948

Establishment of ‘PEPS’ (Patiyala and East Punjab States Union).

1955

Bharat Ratna, India’s highest award, was announced to be given to Prime Minister Pandit Jawaharlal Nehru (1889-1964) by the President of India, Dr. Rajendra Prasad.

1965

The unmanned spacecraft Mariner 4 passed over Mars at an altitude of 6,000 feet and sends back to The Planet Earth the first close-up images of the red planet.

1969

Air Chief Marshal Arjun Singh, Padma Vibhushan, DFC. retired as the Air Officer Commanding, India Command. After retirement he was appointed as the Ambassador in Switzerland.

1971

During a live television and radio broadcast, President Richard Nixon stuned the nation by announcing that he will visit communist China the following year. The statement marked a dramatic turning point in U.S.-China relations, as well as a major shift in American foreign policy.

1986

India protested against China’s intrusion of six to seven km into the Indian territory in Arunachal Pradesh.

1997

Mahesh Chander Mehta, Environmental activist, won Ramon Magsaysay Award.

Related Articles:

Today in History – 14 July

Today in History – 13 July

Today in History – 12 July

Today in History – 11 July

Hermitian Operators: Foundations of Quantum Observables

0
hermitian operators

Table of Contents

  1. Introduction
  2. What Are Operators in Quantum Mechanics?
  3. Definition of Hermitian Operators
  4. Mathematical Properties
  5. Physical Significance
  6. Hermitian vs Non-Hermitian Operators
  7. Spectral Theorem and Diagonalization
  8. Examples of Hermitian Operators
  9. Eigenvalues and Eigenfunctions
  10. Inner Product Space and Adjoint Operators
  11. Self-Adjoint Extensions
  12. Role in the Measurement Postulate
  13. Functional Calculus and Operator Functions
  14. Commutation Relations and Observables
  15. Hermitian Operators in Quantum Information
  16. Conclusion

1. Introduction

In quantum mechanics, physical observables — quantities that can be measured — are represented by Hermitian operators. These operators are central to the structure of quantum theory, ensuring that measurable outcomes are real numbers and that systems can be described in terms of well-behaved eigenstates.


2. What Are Operators in Quantum Mechanics?

Operators act on quantum states in Hilbert space and correspond to physical processes or measurements. Common operators include:

  • Position: \( \hat{x} \)
  • Momentum: \( \hat{p} \)
  • Hamiltonian: \( \hat{H} \)

Operators generalize classical functions in the quantum context.


3. Definition of Hermitian Operators

An operator \( \hat{A} \) is Hermitian (or self-adjoint) if:

\[
\langle \phi | \hat{A} \psi \rangle = \langle \hat{A} \phi | \psi \rangle
\]

Or equivalently:

\[
\hat{A}^\dagger = \hat{A}
\]

Where \( \hat{A}^\dagger \) is the adjoint (conjugate transpose in finite dimensions).


4. Mathematical Properties

Hermitian operators satisfy:

  • Real eigenvalues
  • Orthonormal eigenvectors
  • Spectral decomposition (can be diagonalized)
  • Complete basis of eigenfunctions in Hilbert space

5. Physical Significance

Only Hermitian operators are associated with physical observables because:

  • Measurements yield real numbers
  • Measurement outcomes correspond to eigenvalues
  • Quantum state collapses to eigenstates upon measurement

6. Hermitian vs Non-Hermitian Operators

PropertyHermitianNon-Hermitian
Adjoint\( \hat{A}^\dagger = \hat{A} \)\( \hat{A}^\dagger \ne \hat{A} \)
EigenvaluesRealComplex (in general)
Physical meaningObservableOften auxiliary or non-physical

7. Spectral Theorem and Diagonalization

The spectral theorem states:

Any Hermitian operator \( \hat{A} \) can be written as:

\[
\hat{A} = \sum_n a_n |a_n\rangle \langle a_n|
\]

Where:

  • \( a_n \): eigenvalues
  • \( |a_n\rangle \): orthonormal eigenvectors

In infinite dimensions, the sum becomes an integral over a continuous spectrum.


8. Examples of Hermitian Operators

  • Position operator \( \hat{x} \): acts by multiplication
  • Momentum operator \( \hat{p} = -i\hbar \frac{d}{dx} \)
  • Hamiltonian \( \hat{H} = \frac{\hat{p}^2}{2m} + V(\hat{x}) \)
  • Spin operators: Pauli matrices \( \hat{\sigma}_x, \hat{\sigma}_y, \hat{\sigma}_z \)

All yield real measurement results and satisfy the Hermitian condition.


9. Eigenvalues and Eigenfunctions

Let:

\[
\hat{A} |\psi\rangle = a |\psi\rangle
\]

Then:

  • \( a \in \mathbb{R} \)
  • \( |\psi\rangle \) is normalized and orthogonal to other eigenstates
  • Eigenfunctions form a complete basis

10. Inner Product Space and Adjoint Operators

The adjoint of an operator \( \hat{A} \) is defined via the inner product:

\[
\langle \phi | \hat{A} \psi \rangle = \langle \hat{A}^\dagger \phi | \psi \rangle
\]

In coordinate representation:

  • \( \hat{A} = -i\hbar \frac{d}{dx} \): Hermitian on domain of square-integrable functions with suitable boundary conditions

11. Self-Adjoint Extensions

Some differential operators are formally Hermitian but need domain specification to be truly self-adjoint. This is essential in:

  • Quantum wells
  • Infinite domains
  • Quantum field theory

12. Role in the Measurement Postulate

Upon measurement of observable \( \hat{A} \):

  • Result is one of the eigenvalues \( a \)
  • State collapses to eigenvector \( |a\rangle \)
  • Probability of \( a \):
    \[
    P(a) = |\langle a | \psi \rangle|^2
    \]

This process relies on the Hermitian nature of \( \hat{A} \).


13. Functional Calculus and Operator Functions

Functions of Hermitian operators (e.g., \( f(\hat{H}) \)) are defined via spectral decomposition:

\[
f(\hat{A}) = \sum_n f(a_n) |a_n\rangle \langle a_n|
\]

Used in:

  • Time evolution: \( e^{-i\hat{H}t/\hbar} \)
  • Propagators
  • Quantum statistical mechanics

14. Commutation Relations and Observables

Hermitian operators define algebraic structures:

\[
[\hat{x}, \hat{p}] = i\hbar
\]

  • Basis of Heisenberg algebra
  • Lead to uncertainty principles and canonical quantization

15. Hermitian Operators in Quantum Information

  • Qubit observables: Pauli matrices are Hermitian
  • Density matrices: Hermitian, positive-semidefinite, trace one
  • Quantum gates: generated via exponentials of Hermitian operators

Hermitian matrices define measurements and entanglement criteria.


16. Conclusion

Hermitian operators are indispensable in quantum mechanics. They represent observables, guarantee real outcomes, and provide a basis for understanding measurement, uncertainty, and evolution. Their mathematical properties ensure that quantum theory remains both predictive and internally consistent. A deep grasp of Hermitian operators is essential for mastering quantum systems.


.

Today in History – 14 July

0
today in history 14 july

today in history 14 july

1099

During the First Crusade, Christian knights from Europe captured Jerusalem after seven weeks of siege and began massacring the city’s Muslim and Jewish population.

1636

Aurangzeb was appointed as Shahjahan by Viceroy of Deccan.

1656

Guru Har Kishan, the eight Sikh, was born.

1789

Parisian revolutionaries and mutinous troops stormed and dismantled the Bastille, a royal fortress that came to symbolize the tyranny of the Bourbon monarchs. This dramatic action signaled the beginning of the French Revolution, a decade of political turmoil and terror in which King Louis XVI was overthrown and tens of thousands of people, including the king and his wife Marie Antoinette, were executed.

1798

On this day in 1798, one of the most egregious breaches of the U.S. Constitution in history became federal law when Congress passed the Sedition Act, endangering liberty in the fragile new nation.

1854

Mahendranath Gupt, follower of Ramkrishna Paramahans, was born.

1923

Iqbal Singh Bhatia, great educationist, was born at Kotla Qasim Khan, (Pakistan).

1928

Bedabrata Barua, educationist, social reformer and politician, was born.

1942

Britishers Quit India resolution was passed by Congress Working Committee. They demanded departure of British and agreed on passive resistance until India’s independence. It was declared on 8th August, 1942 at August Kranti Maidan (Gowalia Tank).

1963

Swami Shivanand Saraswati, religious leader, passed away.

1963

Relations between the Soviet Union and China reached at the breaking point as the two governments engage in an angry ideological debate about the future of communism. The United States, for its part, was delighted to see a wedge being driven between the two communist superpowers.

1974

On this day in 1974, U.S. Army General Carl Spaatz, fighter pilot and the first chief of staff of an independent U.S. Air Force, died in Washington, D.C., at age 83.

1992

The Lok Sabha passed a bill seeking to confer on the President the powers of the Legislature of J&K.

1998

India was elected as the chairperson of the World Intellectual Property Organisation’s standing panel on information technology in relation to Intellectual Property Rights.

Related Articles:

Today in History – 13 July

Today in History – 12 July

Today in History – 11 July

Today in History – 10 July

Observables and Measurements: Extracting Physical Reality from Quantum States

0
observables measurements

Table of Contents

  1. Introduction
  2. The Role of Observables in Quantum Theory
  3. Mathematical Representation of Observables
  4. Hermitian Operators and Their Properties
  5. Measurement Postulate
  6. Eigenvalues as Measurement Outcomes
  7. Projection Postulate and State Collapse
  8. Expectation Values and Probabilities
  9. Compatible and Incompatible Observables
  10. Commutators and the Uncertainty Principle
  11. Degeneracy and Simultaneous Measurements
  12. Measurement in Discrete vs Continuous Systems
  13. Generalized Measurements and POVMs
  14. Measurement in Quantum Circuits
  15. Interpretations and Measurement Problem
  16. Conclusion

1. Introduction

In quantum mechanics, observables represent physical quantities we can measure, such as position, momentum, or energy. Unlike classical physics, the act of measurement in quantum theory plays a central and non-trivial role: it not only reveals information but also affects the system being measured.


2. The Role of Observables in Quantum Theory

Quantum mechanics does not assign definite values to observables until they are measured. Instead, it provides probabilities for different outcomes based on the system’s state vector. Observables are the bridge between mathematical states and experimental results.


3. Mathematical Representation of Observables

Observables are represented by Hermitian operators acting on a Hilbert space:

\[
\hat{A}^\dagger = \hat{A}
\]

Key properties:

  • Real eigenvalues (physical measurements must be real)
  • Orthogonal eigenstates
  • Complete spectral decomposition

4. Hermitian Operators and Their Properties

Let \( \hat{A} \) be an observable. Then:

  • \( \hat{A} \) is self-adjoint: \( \hat{A}^\dagger = \hat{A} \)
  • If \( \hat{A}|a\rangle = a|a\rangle \), then \( a \in \mathbb{R} \)
  • Eigenstates form a complete orthonormal basis

This ensures measurable outcomes are consistent and interpretable.


5. Measurement Postulate

Upon measurement of observable \( \hat{A} \) in state \( |\psi\rangle \):

  • The result is one of the eigenvalues \( a \)
  • The system collapses into the corresponding eigenstate \( |a\rangle \)
  • The probability of outcome \( a \) is:

\[
P(a) = |\langle a | \psi \rangle|^2
\]

This is the Born rule.


6. Eigenvalues as Measurement Outcomes

Only the eigenvalues of \( \hat{A} \) are physically observable. All other values are excluded. The spectrum of the operator determines the possible outcomes.


7. Projection Postulate and State Collapse

After measuring \( \hat{A} \) and finding result \( a \), the system is projected into:

\[
|\psi\rangle \rightarrow \frac{\hat{P}_a |\psi\rangle}{|\hat{P}_a |\psi\rangle|}
\]

Where \( \hat{P}_a = |a\rangle\langle a| \) is the projector. This process is known as wavefunction collapse.


8. Expectation Values and Probabilities

The expectation value of \( \hat{A} \) in state \( |\psi\rangle \) is:

\[
\langle \hat{A} \rangle = \langle \psi | \hat{A} | \psi \rangle
\]

It represents the average of many measurements over identically prepared systems.


9. Compatible and Incompatible Observables

Observables \( \hat{A} \) and \( \hat{B} \) are:

  • Compatible if they commute:
    \[
    [\hat{A}, \hat{B}] = 0
    \]
    ⇒ They share a common eigenbasis, and can be measured simultaneously.
  • Incompatible if \( [\hat{A}, \hat{B}] \ne 0 \):
    ⇒ Subject to uncertainty relations

10. Commutators and the Uncertainty Principle

For position and momentum:

\[
[\hat{x}, \hat{p}] = i\hbar
\]

This gives rise to the Heisenberg uncertainty principle:

\[
\Delta x \, \Delta p \ge \frac{\hbar}{2}
\]

Incompatible observables cannot be simultaneously known with arbitrary precision.


11. Degeneracy and Simultaneous Measurements

  • Degenerate eigenvalues: multiple eigenstates share the same eigenvalue
  • Measurement of a degenerate observable does not fully specify the post-measurement state
  • Additional compatible observables can be used to resolve degeneracy

12. Measurement in Discrete vs Continuous Systems

Discrete:

  • E.g., spin, energy levels
  • Finite or countable spectrum

Continuous:

  • E.g., position, momentum
  • Eigenstates are delta-normalized distributions

\[
\langle x’ | x \rangle = \delta(x – x’)
\]


13. Generalized Measurements and POVMs

In generalized quantum measurements:

  • Use POVMs (Positive Operator-Valued Measures)
  • Broader framework than projective measurements
  • Useful in quantum information and open quantum systems

Each outcome \( i \) is associated with operator \( E_i \), such that:

\[
\sum_i E_i = \hat{I}, \quad E_i \ge 0
\]


14. Measurement in Quantum Circuits

  • Measured qubits collapse into \( |0\rangle \) or \( |1\rangle \)
  • Probability dictated by amplitudes
  • Used to extract information from quantum algorithms

Example:
If \( |\psi\rangle = \alpha |0\rangle + \beta |1\rangle \), then:

\[
P(0) = |\alpha|^2, \quad P(1) = |\beta|^2
\]


15. Interpretations and Measurement Problem

  • Copenhagen: collapse is fundamental
  • Many-worlds: all outcomes occur in separate branches
  • Objective collapse models: propose dynamical collapse mechanisms
  • QBism: collapse is Bayesian updating of observer knowledge

Measurement remains the most debated aspect of quantum theory.


16. Conclusion

Observables and measurements lie at the core of quantum mechanics. They define the interaction between abstract state vectors and empirical outcomes. While measurements provide the link to experiment, they also introduce profound conceptual challenges, from wavefunction collapse to the nature of quantum reality. Mastery of this topic is vital for understanding, designing, and interpreting quantum systems.


.
